JOINT SEALANT TO PROVIDE A SOIL TIGHT SEAL WHILE SINGLE OFF-SET PIPE JOINTS ARE SUPPLIED WITH A PROFILE RUBBER GASKET TO PROVIDE A "SILT-TIGHT" OR "WATER-TIGHT" SEAL. ALL RCP IS MANUFACTURED TO APPLICABLE ASTM AND AASHTO STANDARDS, WHILE COMPLYING WITH THE AMERICAN CONCRETE PIPE ASSOCIATIONS Q-CAST CERTIFICATION PROGRAM.
SPECIFICATIONS
- ASTM C 76/AASHTO M 170SPECIFICATION FOR REINFORCED CONCRETE CULVERT PIPE.
- ASTM C 990/AASHTO M198 SPECIFICATION FOR PREFORMED FLEXIBLE JOINT SEALANT.
- ASTM C 443/AASHTO M 361JOINTS FOR CONCRETE PIPE USING RUBBER GASKETS
TONGUE & GROOVE RCP
Pipe ID | LBS/LF | LF/LOAD | WALLTYPE | JTLENGTHS | WALLTHICKNESS | PIPEOD |
|---|---|---|---|---|---|---|
15" | 135 | 320' | B | 4' & 8' | 2-1/4" | 19-1/2" |
18" | 178 | 256' | B | 4' & 8' | 2-1/2" | 23" |
24" | 276 | 168' | B | 4' & 8' | 3" | 30" |
30" | 400 | 120' | B | 4' & 8' | 3-1/2" | 37" |
36" | 532 | 88' | B | 4' & 8' | 4" | 44" |
42" | 686 | 72' | B | 4' & 8' | 4-1/2" | 51" |
48" | 868 | 56' | B | 4' & 8' | 5" | 58" |
54" | 1,118 | 40' | B | 8' | 5-1/2" | 65" |
54" | 1,208 | 32' | C | 8' | 6-1/4" | 66-1/2" |
60" | 1,296 | 32' | B | 8' | 6" | 72" |
60" | 1,473 | 24' | C | 8' | 6-3/4" | 73-1/2" |
66" | 1,737 | 24' | C | 8' | 7-1/4" | 80-1/2" |
72" | 1,812 | 24' | B | 4', 6', 8' | 7" | 86" |
84" | 2,655 | 16' | C | 4' & 8' | 8-3/4" | 101-1/2" |
96" | 3562 | 8' | C | 8' | 9-3/4" | 115-1/2" |
- All Tongue & Groove RCP is manufactured to meet ASTM C 76/AASHTO M 170.
- Tongue & Groove RCP is supplied with Butyl Joint Sealant to meet ASTM C 990/AASHTO M 198.
CONCRETE PIPE IS THE STRONGEST PIPE AVAILABLE THAT PROVIDES BOTH STRUCTURE AND CONDUIT WHEN IT ARRIVES ON THE JOB SITE. UNLIKE FLEXIBLE SYSTEMS, 85% OF CONCRETE PIPE'S STRENGTH IS DESIGNED IN THE PRODUCT, WHILE ONLY 15% OF IT'S STRENGTH IS DEPENDENT ON THE SOIL ENVELOPE. WITH A 100 YEAR DESIGN LIFE, CONCRETE PIPE HAS THE PROVEN TRACK RECORD TO BE THE MOST DURABLE, EFFICIENT, AND RELIABLE PIPE GOSSETT CONCRETE PIPE OFFERS A FULL LINE OF TONGUE & GROOVE AND SINGLE-OFFSET RCP IN CLASS 3, 4, AND 5 STRENGTH. JOINTS ARE SUPPLIED WITH PREFORMED FLEXIBLE
Rubber Gasket RCP
Reinforced Concrete Pipe
Pipe ID | LBS/LF | LF/LOAD | WALLTYPE | JTLENGTHS | WALLTHICKNESS | PIPEOD | BELLOD |
|---|---|---|---|---|---|---|---|
15" | 135 | 320' | B | 8' | 2-1/4" | 19-1/2" | 23-5/16" |
18" | 178 | 256' | B | 8' | 2-1/2" | 23" | 26-1/2" |
24" | 276 | 168' | B | 8' | 3" | 30" | 32-5/8" |
30" | 400 | 120' | B | 8' | 3-1/2" | 37" | 39-1/4" |
36" | 532 | 88' | B | 8' | 4" | 44" | 45-3/8" |
42" | 686 | 72' | B | 8' | 4-1/2" | 51" | 51" |
48" | 868 | 56' | B | 8' | 5" | 58" | 58" |
54" | 1,118 | 40' | B | 8' | 5-1/2" | 65" | 65" |
54" | 1,208 | 32' | B | 8' | 6-1/4" | 66-1/2" | 66-1/2" |
60" | 1,296 | 32' | B | 8' | 6" | 72" | 72" |
60" | 1,473 | 24' | C | 8' | 6-3/4" | 73-1/2" | 73-1/2" |
66" | 1,737 | 24' | C | 8' | 7-1/4" | 80-1/2" | 80-1/2" |
72" | 1,812 | 24' | B | 4', 6', 8' | 7" | 86" | 86" |
84" | 2,655 | 16' | C | 4' & 8' | 8-3/4" | 101-1/2" | 101-1/2" |
96" | 3,562 | 8' | C | 8' | 9-3/4" | 115-1/2" | 115-1/2" |
- All Single Off-Set RCP is manufactured to meet ASTM C 76/AASHTO M 170.
- Joints are manufactured to meet ASTM C 443/AASHTO M 315 and are furnished with Profile Rubber Gaskets.
